6L HDI PCB With Half Hole

Get a Price/Quote

Product Details:

Flame Resistance Level UL 94V-0
Voltage Endurance 500V
Min. Line Width 0.1 mm
Silkscreen White
Test Flying Probe / E-Test
Hole Size 0.2 mm (minimum)
Min. Line Spacing 0.1 mm
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

6L HDI PCB With Half Hole Price And Quantity

Minimum Order Quantity 100 Unit

6L HDI PCB With Half Hole Product Specifications

Voltage Endurance 500V
Board Thickness 1.6 mm
Silkscreen White
Min. Line Width 0.1 mm
Test Flying Probe / E-Test
Hole Size 0.2 mm (minimum)
Surface Finish ENIG (Electroless Nickel Immersion Gold)
Electrical Components Not Included
Min. Line Spacing 0.1 mm
Number Of Layers 6
Board Type Rigid
Soldermask Blue
Panel Size 457 mm x 610 mm
Warranty Yes
Flame Resistance Level UL 94V-0
Impedance Controlled, 10%
Color Blue
Insulation Resistance 10^12
Copper Thickness 1 oz
Product Type PCB
Base Material Alumunium

6L HDI PCB With Half Hole Trade Information

Payment Terms Cash in Advance (CID)
Supply Ability 5000 Unit Per Month
Delivery Time 2-5 Days

Product Description

Experience commanding performance with our acclaimed 6L HDI PCB With Half Holean exceptional reserve for innovative designers. Featuring superb craftsmanship, this majestic circuit board boasts a finished copper weight of 35 m, an impressive aspect ratio of 8: 1, and reliable half-hole and edge plating. Built with advanced HDI technology on durable aluminum, it ensures remarkable savings on maintenance due to its robust RoHS compliance, low moisture sensitivity, and outstanding thermal conductivity. Its blue ENIG surface, refined silkscreen, and precise construction make it the premier choice for high-density applications.

Material Power and Versatile Application

The 6L HDI PCB With Half Hole utilizes a durable aluminum base material, enhanced for high thermal conductivity (1 W/mK) and excellent flame resistance (UL 94V-0). Its application method supports intricate surface mount technology, essential for advanced electronic assemblies. The majestic board is ideal for use in sectors demanding precisionsuch as telecommunications and industrial automation. This rigid PCB can seamlessly integrate within complex electronic systems, thanks to its high insulation resistance and robust finish.

Certifications and Market Eminence

This acclaimed PCB holds RoHS compliance and is environmentally certified as lead-free, continually driving its market value higher. Perfect for both major domestic and international export markets, it is regularly shipped across continents, reflecting commanding global demand. Trusted by manufacturers and suppliers in China, this product is competitively positioned with a superb asking price, ensuring efficient and prompt shipment. Rigorous testing, including flying probe and E-test, confirms its reliability and excellence in every batch.

FAQs of 6L HDI PCB With Half Hole:

Q: How does the half-hole plating on the 6L HDI PCB benefit my design?

A: Half-hole plating enables seamless mounting and soldering of connectors, providing superior edge connectivity for modular designs and compact assemblies.

Q: What is the main process used to manufacture the 6L HDI PCB With Half Hole?

A: This PCB is produced using advanced 1+N+1 microvia HDI technology, ensuring high precision with controlled impedance and reliable electrical pathways.

Q: When is the ideal situation to use this type of PCB?

A: This PCB excels in environments requiring high-density interconnects and space savings, such as telecommunications, medical equipment, and industrial automation.

Q: Where can the 6L HDI PCB With Half Hole be applied?

A: It is tailored for use in complex electronic assemblies needing supreme thermal management and durability, such as routers, servers, and sensitive industrial controls.

Q: What certifications guarantee the quality and safety of this PCB?

A: The board is RoHS and lead-free certified, boasting UL 94V-0 flame resistance compliance and meeting rigorous electrical safety standards.

Q: How does the aluminum base material enhance the products performance?

A: Aluminum imparts excellent thermal conductivity and enhances the PCBs overall stability, making it fit for high-performance, heat-intensive applications.
